Mobilator Drive (1 HP) Spec Sheet

Lesa Snider
  • Updated

Key Features

  • 1 HP perpendicular drive
  • Single axis tacking
  • Multiple configurations
  • Pneumatic cylinder engages and disengages drive wheel
  • Pneumatic brakes

Description

TAIT Mobilator PT units provide linear motion to stage wagons and set pieces. They have pneumatically driven brakes and drive system that allows free movement of the pieces. They can be paired with TAIT smart air compressors and encoders to be controlled by TAIT Navigator or operated locally. The Mobilator can be integrated with our Mag Deck system.

Specifications

Electrical
Motor 180 VDC
Connections
Power L21-30 Cable, 208V 3 Phase
Control Local, TAIT Navigator, Pickle
L22-30 motor and brake (no limits)
Pneumatic line for brakes, drive engage
Mechanical
Maximum Speed 0.58 m/s (1.92 ft/s)
Construction
Dimensions (L x W x H) 0.91 m x 0.19 m x 0.23 m (3 ft x 8 ft x 9 ft)
Weight 45.36 kg (100 lbs)


Dimensions

Top View Front View
Mobilator_perpendicularDrive_Top_Dimensions_v2.png Mobilator_perpendicularDrive_Side_Dimensions_v2.png

Configuration Examples

Mobilator_1hp_Configuration_EltonJohn_Danish_flatshot.png Mobilator_Universal_89-3_4inch_Set_configuration_Fshot.png

Still Have Questions?

If you have any questions at all--or if you're ready to rent--please contact us. We look forward to hearing from you soon!

Disclaimer: These specifications are general guidelines only and may not be appropriate for your particular project. All product specifications and Data are subject to change without notice. Data, performance features, and images may vary from the final project quote. Issue date: 2022.05.17. Copyright 2022 TAIT Towers Manufacturing, LLC. All rights reserved.

I-CODE: 23680120
