Telescoping Mast Lift Spec Sheet – TAIT Support

Key Features

Telescoping Mast Lift extends to a maximum height of 9.14 m (30 ft) or contract during a performance
Supports various mounting brackets that connect to lighting or staging elements
The entire lift is integrated into a self-contained dolly for quick unloading and installation.
Integrates with TAIT Navigator and iQ systems allowing precise speed and position control


Description

The TAIT Telescoping Mast Lift is a versatile stage element that can lift props or lights to a height of 9.14 m (30 ft) above the stage. The Lift can retract to 2.29 m (7.50 ft) or stop anywhere in between, adding dynamic motion to a production. Lift loads up to 226.08 kg (500 lbs) at a speed of 0.74 m/s (2.46 ft/s). Telescoping Lift is compatible with the TAIT Navigator Automation Systems giving user precise speed and motion control.

Specifications

Connections
Control	TAIT Navigator
Mechanical
Maximum Lift Speed	0.74 m/s (2.43 ft/s)
Maximum Lift Capacity	226.08 kg (500 lbs)
Maximum Travel	2.29 m to 9.14 m (7.51 ft to 30 ft)
Rise	6.85 m (22.50 ft)

Construction
Dimensions (L x W x H)	Telescoping Lift, collapsed: 1.41 m x 1.22 m x 2.28 m (4.62 ft x 4 ft x 7.48 ft) Telescoping Lift, expanded: 1.41 m x 1.22 m x 9.14 (4.62 ft x 4 ft x 30 ft)
Material	Dolly: Steel Telescoping Masts: Aluminum

Dimensions

Front View with Lights	Front View, Collapsed for Shipping

Top View with Lights

Packaging and Shipping

Dimensions (L x W x H)	1.42 m x 1.22 m x 2.29 m (4.66 ft x 4 ft x 7.51 in)
Weight	1360.78 kg (3000 lbs)

Still Have Questions?

If you have any questions at all--or if you're ready to rent--please contact us. We look forward to hearing from you soon!

Disclaimer: These specifications are general guidelines only and may not be appropriate for your particular project. All product specifications and Data are subject to change without notice. Data, performance features, and images may vary from the final project quote. Issue date: 2021.03.21. Copyright 2021 TAIT Towers Manufacturing, LLC. All rights reserved.

I-CODE: 25200700
