TAIT Sculptor Winch Spec Sheet

Daniel Proctor
  • Updated

Key Features

  • Compact winch ideal for lifting props and art installations
  • Incorporates "zero-fleet" technology
  • 1.5 mm Dyneema rope (x2)
  • 4kW servo motor with absolute encoder
  • Complies with hoist safety standards of EN17206
  • Control via Nav:Net and Ethernet
  • Integrates with TAIT Navigator and iQ systems
 Angle Front.png

Description

The TAIT Sculptor Winch is a compact, lightweight, low noise winch ideal for prop flying and kinetic art installations. The high safety rating enables the winch to lift objects over
people if needed.

Conforming to EN17206, the winch features single and dual line options, a servo motor, an absolute safety encoder, brake monitoring, initial and ultimate limits, and zero-fleet technology. The winch features an in-built drive, meaning no additional drive unit is required to run it, thus saving space.

The winch uses onboard Nav:Net safety communications via Beckhoff and can be controlled as a standalone unit or in a system of multiple units via TAIT Navigator software and consoles.

Duty cycles of up to 100% are achievable due to the long lifetime of the winch components.

Specifications

Software Compatibility
Control System TAIT Navigator and iQ
Electrical
Voltage 208/400 V, 50-60 Hz
Current Standby: 0.15 A
Running peak: 1.5 A
Brakes Dual, low-noise and monitored
Motor type 4kW Servo with absolute encoder (EnDat)
Max no of daisy-chained units Power: 13
Data: Unlimited
Connections
Mains In / Out Neutrik True1
Data Neutrik Ethercon x2
Drive type In-built (no external controller required)
Mechanical
Max duty cycle 100% (continuous operation 24/7)
Entertainment Load Limit (ELL) 6 kg (13.2 lbs)
Vertical travel (Stroke) 9 m (29.5 ft)
Max speed 0.7 m/s (2.3 ft/s)
Min speed 0 m/s
Rope type 1.5 mm diameter
Rope quantity 2
Suspension 2 x M12 mounting threads on top surface
Limits 2 x Ultimate, 2 x Initial
Direct struck non-adjustable carriage limits
Compliance
Standards SIL 3 (EN 61508)
EN17206 : 2020


Dimensions

Front View Side View
Front dimensions.PNG Side dimensions.PNG



Still Have Questions?

If you have any questions, please contact us. We look forward to hearing from you soon!

Disclaimer: These specifications are general guidelines only and may not be appropriate for your particular project. All product specifications and Data are subject to change without notice. Data, performance features, and images may vary from the final project quote. Issue date: 2024.11.01. Copyright 2024 TAIT Towers Manufacturing, LLC. All rights reserved.
