Key Features
|
Description
The TAIT Matrix Lift is a custom electrically-powered product that lifts props or performers to a height of 2.44 m (8.0 ft) above the stage. Each lift contains two lifting columns, and the entire unit is integrated into a dolly; reducing the time and personnel needed to install the Matrix Lift. The Matrix Lift integrates seamlessly with the TAIT Mag Deck system. The hydraulically-actuated feet allow the lift to work with varied staging heights and ensure an even surface for performer safety. The versatility and the flexibility of the Matrix Lift make it easy to add motion elements for a dramatic stage production.
Specifications
| Connections | ||
| Control | TAIT Navigator and iQ | |
| Mechanical | ||
| Maximum Lift Speed | 0.45 m/s (1.48 ft/s) | |
| Maximum Lift Capacity | 225 kg (496 lbs) | |
| Maximum Travel | 2.29 m to 4.73 m (7.51 ft to 15.51 ft) | |
| Rise | 2.44 m (8.0 ft) | |
| Construction | ||
| Dimensions (L x W x H) | Retracted Extended |
2.74 m x 1.14 m x 2.29 m (9.0 ft x 3.7 ft x 7.5 ft) 2.74 m x 1.14 m x 4.72 (9.0 ft x 3.7 ft x 15.5 ft) |
| Performer Platform (L x W) | Single Column | 1.12 m x 1.12 m (3.67 ft x 3.67 ft) |
Dimensions
| Front View, retracted | Top View |
| Front View, Extended | ISO View, One Column Retracted |
Packaging and Shipping
| Dimensions (L x W x H) | 2740 mm x 1140 mm x 2290 mm (107.9 in. x 44.9 in. x 90.2 in.) |
| Weight | 2045.7 kg (4510 lbs) |
Still Have Questions?
If you have any questions at all--or if you're ready to rent--please contact us. We look forward to hearing from you soon!
Disclaimer: These specifications are general guidelines only and may not be appropriate for your particular project. All product specifications and Data are subject to change without notice. Data, performance features, and images may vary from the final project quote. Issue date: 2021.10.20. Copyright 2021 TAIT Towers Manufacturing, LLC. All rights reserved.
I-CODE: 25200700, 252500210K (Kit)
